Custom Steel Frame Building For Activity Centers Fast Construction

Brand Name : YDX

Model Number : YDX-D4S

Certification : CE ISO SGS

Place of Origin : CHINA,QINGDAO

MOQ : 10-10000 square meters

Price : $30.00-$65.00

Payment Terms : T/T

Supply Ability : 10000 tons/month

Delivery Time : 20-30 works days

Packaging Details : Exported standard packing

Drawing : CAD, TEKLA, 3D Model, PKPM, BIM

Connect : Bolt/Weld

Speed Of Construction : Fast

Corrosion Resistance : High

Cladding : PU/Rock Wool/Fiberglass/EP

Windows : Aluminum

Product Flexibility : Flexible

Apply : Easy to Apply

Design : Custom For Free

Frame Type : Steel Frame

Installation Time : Short

Installation : Engineer Guidance On Site

Shape : As The Customer Request

Door : Sliding Door or Rolling Door

Structure Type : Frame

Earthquake Resistance : Strong

Seismic Design : High Seismic Zone

Aesthetics : Modern

Construction Type : Frame

Cost : Moderate

Product Resistance : Corrosion Resistant

Finish : Galvanized/Painted/Cladding

Roof : Glass Wool, EPS, PU

Product Fire Resistance : Fireproof

Contact Now

Portal Steel Frame Structure Building For Activity Center

Project Introduction:

Welded H section steel beams and columns are connected by high strength bolts to be the main steel frame structure. Clean span that without center column could provide large space. Double row windows light up inside. Environmental epoxy floor coating has better dustproof property and makes the floor smooth. It also has a double storeys office building inside.

Project Details:

Steel structure building
1. Primary Framing		Box beam column, cross steel column, H-shaped steel column, steel beam
2. Secondary Framing		Galvanized Z and C sections purlin
3. Roof and Wall panels		Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU).
4. Steel Decking Floor		Galvanized steel decking board
5.Structural subsystem		Divider, gutter, awning, partition wall
6.Mezzanines, Platforms		Painted or galvanized H beam
7.Other Building Accessories		Sliding doors, roll up doors, aluminium windows, louvers, etc.
Service Life	50-70years		support	steel angle, steel pipe, steel round
Place of Origin	Qingdao,Shandong,China		Application	workshop, warehouse, poultry house,garage etc
Grade	Q235B, Q355B or as per customer's need		Bolt Grade	M20, M16, M14 etc
Connection	intensive bolt, ordinary bolt		Window	PVC steel or aluminum alloy
Downspout	PVC pipe or as per customer's request		Door	sliding or rolling door
Purlin	C/Z shape profile		Panel	EPS/PU/fiber glass/rock wool
Main Frame	Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Drawings & Quotation:
(1) Customized design is welcomed.
(2) In order to promise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.We will quote for you promptly.

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame	Steel Column & Beam	1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
		2. Surface: Hot Dip Galvanized or Painted;
		3. Connection: All Bolts Connection;
Supporting System	Roof Purlin	C or Z Section Steel, Q235B
	Wall Purlin	C or Z Section Steel, Q235B
	Bracing	Steel Rod, Q235B
	Cross Support	Steel Rod, Q235B
	Column Support	Angle Steel; Steel Rod; Q235B
	Angle Brace	Angle steel,Q235B
	Tie Bar	Steel Pipe,Q235B
	Roof & Wall System	1. Single Colorful Corrugated Steel Sheet; Thickness: 0.3-0.8mm
	Roof & Wall System	2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU; Thickness: 50-150mm;
Accessories	Door	Sliding; Rolled Up Door (Manual/Auto)
	Window	Aluminum Alloy; PVC;
	Downspout	PVC pipe;
	Gutter	Galvanized Steel Sheet; Stainless Steel
	Ventilator	Stainless Steel Turbine Ventilator
	Skylight Belt	FRP or PC semi-transparent Skylight Belt
	Flash	Color Steel Sheet
	Fittings	Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc

Advantages of prefabricated steel structure buildings:

1	High strength and light weight	Although the density of steel is larger than that of other building materials, its strength is very high. Under the same force, the steel structure has a small weight and can be made into a structure with a large span.
2	Good plasticity and good toughness	The plasticity of the steel is good, and the structure will not suddenly break due to accidental overload or partial overload. The toughness of the steel is good, making the structure more adaptable to dynamic loads.
3	High degree of industrialization in production	The steel structure is mainly produced in a specialized metal structure factory, so the production is simple and the precision is high.
4	Simple construction and short construction period	All components are prefabricated at the factory, and the site is simply assembled, which greatly shortens the construction period.
5	Wind resistance and structural stability	Steel structure construction with light weight, high strength, good overall rigidity and strong deformation ability
6	Saving construction costs	The steel structure has light weight, reduces the basic cost, and has a fast construction speed. It can be completed and put into operation as soon as possible, and the comprehensive economic benefits are much better than the concrete structure.
7	Recyclable	Steel can be recycled, less environmentally polluted when constructed and removed
